Click or tap the input field of File Name to input the file name t
o be saved with
the pop-up virtual keypad.
• Set the file path
Click or tap the input field of
File Path, then the disk management inter
face is
displayed. Select the target file path and then click or tap
OK. For detailed
operations, refer t
o descriptions in
Disk Management
.
When a USB device is not connected, the default file path is the "Local Disk";
when a USB device is detected, the path is automatically set to "D:".
• Overlay
Click or tap the
Overlay on/off swit
ch to enable or disable the overwriting
function. When this function is enabled, the existing file in the specified file path
will be overwritten by the newly saved file that has the same filename as the
existing one.
Click or tap
Save, the current setup file is sav
ed based on the settings and the storage
menu is disabled.
TIP
When the quick action function is set to "Sav
e Setup" or "Save Group" with "Save Setup"
selected, you can press the front-panel
key to save the setup.
19.2.4 Binary Data Format (.bin)
Binary data format stores waveform data in binary format and provides data headers
that describe these data. As data are display
ed in binary format, its file size is much
more smaller than that in ASCII format. If several channels are enabled, then all the
displayed channels will be saved (save the first channel then save the second, and
then it goes on like this until all the displayed channels are saved).
Table 19.1 BIN File Format
File
Header
Waveform
Header
Waveform
Data
Header
Channel
Data
Waveform
Header
Waveform
Data
Header
Channel
Data
16 Bytes 140 Bytes 16 Bytes n Bytes 140 Bytes 16 Bytes n Bytes
In BIN file format, it contains the following channel data:
• CH1 Data
• CH2 Data
• CH3 Data
• CH4 Data
Store and Load
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DHO1000 User Guide
219
