10.2.1.2 Count Values

The default values for threshold upper limit and threshold low limit are 90% and

10%, respectiv

ely.

Positive Pulse Count

It is specified as the number of positive pulses that rise from under the threshold

lower limit to above the threshold upper limit.

Positive Pulse Count = n

1 n2

Threshold

Uppe

r Limit

Threshold

Lower

Limit

Negative Pulse Count

It is specified as the number o

f negativ

e pulses that fall from above the threshold

upper limit to below the threshold lower limit.

1 n2

Negative Pulse Count = n

Threshold

Upp

r Limit

Threshold

Lower

Limit

Rising Edge Count

It is specified as the number of rising edges that rise from under the threshold lower

limit to above the threshold upper limit.

Measurements

DHO1000 User Guide

140
