Document Overview
This manual gives you a quick overview of the front and rear panel, user interface as
well as basic operation methods of DHO1000 series.
Publication Number
UGA32101-1110
Software Version
Software upgrade might change or add product features. Please acquire the latest
version of the manual from RIGOL
Format Conventions in this Manual
1. Key
The front panel key is denoted by the menu key icon. For example,
indicates the "DEFAULT" key.
2. Menu
The menu item is denot
ed by the format of "Menu Name (Bold) + Character
Shading" in the manual. For example,
Setup indicates the "Setup" sub-menu under
the "Utility" function menu. Y
ou can click or tap
Setup to access the "Setup" menu.
3. Operation Pr
ocedures
The next step of the operation is denoted by ">" in the manual. For example,
> Storage indicates first clicking or tapping and then clicking or tapping
Storage.
4. The front/rear p
anel connector is denoted by "Brackets + Connector Name (Bold)",
for example, [AUX OUT].
5. Knob
Label Knob Label Knob
Horizontal
POSITION
Horizontal Position
Knob
1
Multipurpose
Knob 1
Document Overview
