10.2 Auto Measurements
You can enter the Measure menu in the following ways.
• Click or tap the function navigation icon at the lower-left corner of the
screen, and then select Measure to enter the "Measure" menu.
• Pr
ess the front-panel
key to enter the "Measure" menu.
• Click or tap the Measure button on the t
oolbar to enter the "Measure" menu.
• In
Vertical System
menu, click or tap the
Measure button t
o enter the "Measure"
menu.
10.2.1 Measurement Parameter
This oscilloscope allows you to set the measurement source, enable or disable the all
measurement function, the statistical function, and et
c. You can make quick
measurements for many waveform parameters. The measurement results will be
displayed in the
Result sidebar at the right section o
f the screen.
TIP
If there is no signal input for the curr
ent source or the measurement result is not within the
valid range (too large or too small), then the measurement results are invalid, and "*****" is
displayed on the screen. Please re-input the signal or set the signal.
Measurements
DHO1000 User Guide
138
