Window Transparency
In the Display setting menu, drag the slider of Window Transparency to set the
window transp
arency. The default is 50%, and the range available is from 0% to 100%.
Cursor Brightness
In the
Display setting menu, drag the slider of Cursor Brightness to set the cur
sor
brightness. The default is 80%, and the range available is from 0% to 100%.
18.6 Show Scale
In the Display setting menu, click or tap the Show Scale on/off swit
ch to enable or
disable scale display on the screen. By default, it is ON.
18.7 Color Grade
In the Display setting menu, click or tap the Color Grade on/off swit
ch to enable or
disable the color grade display. By default, it is OFF.
When it is enabled, different colors are displayed on the screen to indicate the times
of data acquisition or acquisition probability.
18.8 Waveform Freeze
In the Display setting menu, click or tap the Waveform Freeze on/o
ff switch to
enable or disable the waveform freeze function. By default, it is ON.
When the function is enabled, the oscilloscope displays the waveform after multiple
sampling and superposition when sampling is stopped. You can click or tap the
STOP/RUN button at the upper
-right side of the screen or press the front-panel
key to stop sampling. If this function is disabled, the last triggered waveform is
displayed.
Display Control
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DHO1000 User Guide
213
