Rigol DHO1000 Series User Manual

If you select "Manual", set the following parameters:
• Click or tap the Top toggle button to select Histogram or Max-Min as the top
v
alue measurement method.
• Click or tap the
Base toggle button to select Histogram or Max-Min as the base
v
alue measurement method.
TIP
If you select "Manual" for the amplitude method, the measur
ement results of other parameters
may be affected.
"Histogram" and "Max-Min" are the internal measurement algorithm for the oscilloscope.
Remove the Measurement Results
Refer to Remove the Measurement Results .
Statistics
Click or tap the
Statistic on/off swit
ch to enable or disable the statistical function.
This oscilloscope can make a statistics and display the current values of multiple
parameters, as shown in the figure below.
• Click or tap any measurement it
em in the "Result" sidebar at the right side of the
screen and a window is displayed. Click or tap
Reset Stat. to clear the hist
ory
statistics data and makes statistics again. You can also click or tap
Reset Stat. in
the measurement setting menu.
• Click or tap the input field o
f
Count and use the pop-up numeric keyp
ad to set
the count value. You can also use the corresponding multipurpose knob to set
the value. Its range is from 2 to 100,000. Its default value is 1000.
Measurements
DHO1000 User Guide
150
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
