To Next Page

To Previous Page

Close the Cursor Measurement Result Window

When cursor measur

ement is enabled, you can disable it in the following ways:

• In the

Cursors menu, click or tap the Remove button t

o disable cursor

measurements.

• In the "Result" bar at the right side of the screen, click or tap the "Cursors" label

and then click or tap

Remove in the pop-up window.

• In the "R

esult" bar at the right side of the screen, drag the "Cursors" label to the

right to simply disable cursor measurements.

• Press the front-panel

key to disable cursor measurements.

Measurements

DHO1000 User Guide

160
