Parameter Factory Settings

AX BX OFF

AY -6 μs

BY 6 μs

Track

AX Source CH1

BX Source CH1

AX BX OFF

Track X

AX -6 μs

BX 6 μs

Select X

AX BX OFF

AX -150 mV

BX 150 mV

Counter

Source CH1

Statistic OFF

Measure Frequency

Resolution 4

DVM

Source CH1

Mode AC RMS

Beeper OFF

Upper Limit 1 V

Lower Limit 0 V

Save Image

Format *.png

Invert OFF

Color Color

Header ON

Overlay OFF

Save Wave

Data Source Screen

Format *.bin

Save Setup

File Type *.stp

Appendix

DHO1000 User Guide

247

www.calcert.com sales@calcert.com1.888.610.7664
