Parameter Factory Settings

SourceA CH1

SourceB CH1

Scale 500 mU

Offset 0 U

A÷B

Operation OFF

SourceA CH1

SourceB CH1

Scale 500 mU

Offset 0 U

FFT

Operation OFF

Source CH1

X Span-Center

Unit dBm/dBV

Center Frequency 5 MHz

Frequency Span 10 MHz

Vertical Scale 20 dBV

Offset 0 dBV

Window Function Hanning

Color Grade OFF

Peak Search OFF

Peak Number 5

Threshold 5.5 dBV

Excursion 1.8 dBV

Table Order Amp Order

A&&B

Operation OFF

SourceA CH1

SourceB CH1

Wave Size Medium

Offset 0 div

Sensitivity 300 mdiv

Thre.CH1 0 V

Thre.CH2 0 V

Thre.CH3 0 V

Thre.CH4 0 V

A||B

Operation OFF

SourceA CH1

SourceB CH1
