Rigol DHO1000 Series User Manual

6. Trigger Label
- Displays the trigger information o
f the system, including the trigger type,
trigger level, trigger mode, and etc.
- Click or tap the trigger label, then the trigger setting window is displayed. You
can set the parameters for the trigger.
7. Function Toolbar
Provides
STOP/RUN, XY, Default, Flex Knob, Navigate keys and some function
k
eys in the function navigation menu.
8. Result Sidebar
Displays the measurement results and statistics of various functions. Click or tap
at the lower-right corner of the screen to open or close the "Result" sidebar.
9. Notification Ar
ea
Displays USB icon, LAN icon, the sound icon, remote control icon as well as data
and time. You can click or tap this area to open the "Utility" menu.
- USB storage device icon: When a USB storage device is detected,
will be
display
ed.
- L
AN icon: When the LAN interface is successfully connected,
is displayed.
- Sound icon: In the "Utility" menu, click or tap Setup > Beeper to enable or
disable the sound. When on, will be displayed; when off, will be
displayed. Y
ou can simply click or tap the icon to enable or disable the sound.
- Remote control icon: When you use Web Control to control the instrument
remotely,
will be displayed.
- Date and time: displays the system date and time. For how to set the data and
time, please refer to
Display Date and Time .
10. Split-screen Display
If you enable multiple functions, multiple windows can be displayed on the screen
at one time.
11. Math Labels
Displays the on/off state, operation type, and vertical scale.
12.
Channel Labels
- Display the on/off status of CH1~CH4.
- Display the channel coupling mode.
Quick Start
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DHO1000 User Guide
27
