RKC INSTRUMENT PF900 User Manual

6. PROGRAM CONTROL
IMR02L04-E3
6-20
 Control action at Pattern end [Setup setting mode]
Set control action at Pattern end.
Parameter symbol Data range Factory set value
End.P
PID control, Heat/Cool PID control or
Position proportioning PID control (With FBR input):
0: Control continued 1: Control stop
Position proportioning PID control
(When there is no FBR input or the FBR input is break):
0: Control continued
1: Open-side output OFF, Close-side output OFF
2: Open-side output OFF, Close-side output ON
3: Open-side output ON, Close-side output OFF
0
 Transmission output action at Pattern end [Engineering mode F30.07]
Set action of Transmission output at Pattern end.
Parameter symbol Data range Factory set value
P.E d.A o
0: Action stop 1: Action continued
00000 Value at SV display
OUT2
OUT3
Unused
00000
 Event action at Pattern end [Engineering mode F30.08]
Set event action at Pattern end.
Parameter symbol Data range Factory set value
P.E d.E V
0: Action stop 1: Action continued
00000 Value at SV display
Event 1
Event 2
Event 3
Event 4
HBA1, HBA2
00000
 Pattern end output action at Pattern repeat/Pattern link
[Initial level engineering mode F80.08]
Set Pattern end output action at Pattern repeat/Pattern link.
Parameter symbol Data range Factory set value
PE.SL
0: OFF 1: ON (0.5 seconds)
00000 Value at SV display
Pattern end output is ON at Pattern repeat.
Pattern end output is ON at Total pattern repeat.
Pattern end output is ON at Pattern link.
Unused
00000
For Pattern end output action at Repeat or Link, refer to 4.5.6 Initial level engineering mode
of the PF900/PF901 Instruction Manual (IMR02L03-E) on the CD-ROM.
