4. BASIC OPERATION
IMR02L04-E3
4-20
Continued from the previous page.
Name Symbol Data range
Factory set
value
Wait time-out set value
TM.OUT
From 0:00 to 500:00 (Hour: Minute), or
from 0:00 to 500:00 (Minute: Second)
0:00 (Hour: Minute or Minute: Second): Unused
0 hour
00 minute
Time signal memory group setting block (
TM.SIG
)
Time signal memory group number
P TS.GR
1 to 16
1
Time signal output assignment
01.OUT
1 to 8: Time signal 1 to 8
0: No assignment
0
Start segment of time signal
01.S.SN
1 to 99
Within the maximum segment number.
1
Time signal start time
01.S.TM
From 0:00 to 500:00 (Hour: Minute), or
from 0:00 to 500:00 (Minute: Second)
0 hour
00 minute
End segment of time signal
01.E.SN
1 to 99
Within the maximum segment number.
1
Time signal end time
01.E.TM
From 0:00 to 500:00 (Hour: Minute), or
from 0:00 to 500:00 (Minute: Second)
0 hour
00 minute
Output program memory group setting block (
PRG.MV
)
Output program memory group
number
a
P.MV.GR
1 to [128/Maximum number of segments]
Up to 99
1
Output program value 1
a
P.MV1

5.0 to

105.0 %

5.0
Output program value 2
b
P.MV2

5.0 to

105.0 %

5.0
Output program value 3
c
P.MV3

5.0 to

105.0 %

5.0
Level PID setting block (
LV.PID
)
Level PID setting 1
LEVL.1
Input range low to Level PID setting 2
Input range
high
Level PID setting 2
LEVL.2
Level PID setting 1 to Level PID setting 3
Input range
high
Level PID setting 3
LEVL.3
Level PID setting 2 to Level PID setting 4
Input range
high
Level PID setting 4
LEVL.4
Level PID setting 3 to Level PID setting 5
Input range
high
Level PID setting 5
LEVL.5
Level PID setting 4 to Level PID setting 6
Input range
high
Level PID setting 6
LEVL.6
Level PID setting 5 to Level PID setting 7
Input range
high
Level PID setting 7
LEVL.7
Level PID setting 6 to Input range high
Input range
high
Reset mode setting block (
RESET
)
Set value (SV) in Reset mode
SV
Setting limiter low to Setting limiter high 0
Manipulated output value 1 (MV1) in
Reset mode
MV1

5.0 to

105.0 %

5.0
Manipulated output value 2 (MV2) in
Reset mode
MV2

5.0 to

105.0 %

5.0
Event memory group number in
Reset mode
EV.GR
0 to 8
0: Event OFF
1
Fixed set point control mode setting block (
FIX
)
Set value (SV) in Fixed set point
control mode
SV
Setting limiter low to Setting limiter high 0
PID memory group number in Fixed
set point control mode
PID.GR
0 to 8
0: Level PID
0
Event memory group number in
Fixed set point control mode
EV.GR
0 to 8
0: Event OFF
1
a
Displays when Output program value 1 is assigned to OUT1.
b
Displays when Output program value 2 is assigned to OUT2.
c
Displays when Output program value 3 is assigned to OUT3.
Continued on the next page.
