RuggedCom RSG2488

Chapter 4
System Administration
RUGGEDCOM RSG2488
User Guide
100 Configuring an Alarm
Figure 66: Alarms Table
2. Select an alarm. The Alarms form appears.
10
8
9
7
6
5
4
3
2
1
Figure 67: Alarms Form
1. Name Box 2. Level Box 3. Latch Box 4. Trap Box 5. Log Box 6. LED & Relay Box 7. Refresh Time Box 8. Apply
Button 9. Delete Button 10. Reload Button
3. Configure the following parameter(s) as required:
