Page #62 background imageLoading...
Page #62 background image
Chapter 3
Device Management
RUGGEDCOM RSG2488
User Guide
50 Uploading/Downloading Files Using XMODEM
main.bin – the main ROS application firmware image
boot.bin – the boot loader firmware image
fpga.xsvf – the FPGA firmware binary image
config.csv – the complete configuration database, in the form of a comma-delimited ASCII text file
banner.txt – contains text that appears on the login screen
The following sections describe how to upload and download files:
Section 3.5.1, “Uploading/Downloading Files Using XMODEM”
Section 3.5.2, “Uploading/Downloading Files Using a TFTP Client”
Section 3.5.3, “Uploading/Downloading Files Using a TFTP Server”
Section 3.5.4, “Uploading/Downloading Files Using an SFTP Server”
Section 3.5.1
Uploading/Downloading Files Using XMODEM
To updload or download a file using XMODEM, do the following:
NOTE
This method requires a host computer that has terminal emulation or Telnet software installed and the
ability to perform XMODEM transfers.
NOTE
Xmodem transfers can only be performed through the serial console, which is authenticated during
login.
1. Establish a direct connection between the device and the host computer. For more information, refer to
Section 2.1.1, “Connecting to ROS Through a Direct Connection”.
2. Log in to the device as an admin user and access the CLI shell. For more information about accessing the
CLI shell, refer to Section 2.6, “Using the Command Line Interface”.
NOTE
The send option sends files to the host computer, while the receive option pulls files from the
host computer.
3. At the CLI prompt, type:
xmodem [ send | receive ] filename
Where:
filename is the name of the file (i.e. main.bin)
NOTE
If available in the terminal emulation or Telnet software, select the XModem 1K protocol for
transmission over the standard XModem option.
4. When the device responds with
Press Ctrl-X to cancel
