Chapter 3
Device Management
RUGGEDCOM RSG2488
User Guide
48 Viewing the Status of the Power Supplies
Section 3.3
Viewing the Status of the Power Supplies
To view the current status of the power supplies, navigate to Diagnostics > Power Supply Status. The Power
Supply Status table appears.
Figure 10: Power Supply Status Table
This table displays the following information:
Parameter Description
ID Synopsis: 1 to 2
Voltage Synopsis: 0 to 4294967295 mV
The millivolt output voltage.
Current Synopsis: 0 to 4294967295 mV
The milliamp per volt output current.
Temperature Synopsis: -32768 to 32767 C
The temperature of the power supply.
InStatus Synopsis: { ----, Out of range , Good }
Specifies whether or not the power supply input voltage is in range.
For dual DC/DC power supplies, the input voltage range is between 36 and 72 V.
For dual AC/DC power supplies, the input voltage range for AC is between 85 and 264 VAC
and, for DC, 95 and 300 VDC.
OutStatus Synopsis: { ----, Out of range , Good }
Specifies whether or not the power supply output voltage is in range. The output voltage
range is 12 V +/- 1%.
Section 3.4
Restoring Factory Defaults
The device can be completely or partially restored to its original factory default settings. Excluding groups of
parameters from the factory reset, such as those that affect basic connectivity and SNMP management, is useful
when communication with the device is still required during the reset.
The following categories are not affected by a selective configuration reset:
• IP Interfaces
• IP Gateways
