RUGGEDCOM RSG2488
User Guide
Chapter 5
Setup and Configuration
Managing Virtual LANs 111
Setup and Configuration
This chapter describes how to setup and configure the device for use on a network using the various features
available in ROS. It describes the following tasks:
• Section 5.1, “Managing Virtual LANs”
• Section 5.2, “Managing Spanning Tree Protocol”
• Section 5.3, “Managing Classes of Service”
• Section 5.4, “Managing MAC Addresses”
• Section 5.5, “Managing the System Time”
• Section 5.6, “Managing SNMP”
• Section 5.7, “Managing Network Discovery”
Section 5.1
Managing Virtual LANs
A Virtual Local Area Network (VLAN) is a group of devices on one or more LAN segments that communicate as if
they were attached to the same physical LAN segment. VLANs are extremely flexible because they are based on
logical connections, rather than physical connections.
When VLANs are introduced, all traffic in the network must belong to one VLAN or another. Traffic on one VLAN
cannot pass to another, except through an inter-network router or Layer 3 switch.
VLANs are created in two ways:
• Explicitly
Static VLANs can be created in the switch. For more information about static VLANs, refer to Section 5.1.4,
“Managing Static VLANs”.
• Implicitly
When a VLAN ID (VID) is set for a static MAC address or IP interface, an appropriate VLAN is automatically
created if it does not yet exist.
For more information about VLANs, refer to Section 5.1.1, “VLAN Concepts”.
The following sections describe how to configure and manage VLANs:
• Section 5.1.1, “VLAN Concepts”
• Section 5.1.2, “Viewing a List of VLANs”
• Section 5.1.3, “Configuring VLANs for Ethernet Ports”
• Section 5.1.4, “Managing Static VLANs”
