Chapter 5
Setup and Configuration
Configuring DSCP to CoS Mapping 153
Figure 104: Priority to CoS Mapping Table
2. Select a priority level. The Priority to CoS Mapping form appears.
43
2
1
Figure 105: Priority to CoS Mapping Form
1. Priority Box 2. CoS List 3. Alarm Button 4. Reload Button
3. Configure the following parameter(s) as required:
Parameter Description
Priority Synopsis: 0 to 7
Default: 0
Value of the IEEE 802.1p priority.
CoS Synopsis: { Normal, Medium, High, Crit }
Default: Normal
CoS assigned to received tagged frames with the specified IEEE 802.1p priority value.
4. Click Apply.
Section 5.3.4
Configuring DSCP to CoS Mapping
Mapping CoS to the Differentiated Services (DS) field set in the IP header for each packet is done by defining
Differentiated Services Code Points (DSCPs) in the CoS configuration.
To map a DSCP to a Class of Service, do the following:
1. Navigate to Classes of Service > Configure DSCP to CoS Mapping. The DSCP to CoS Mapping table
appears.
