RuggedCom RSG2488 User Manual

RUGGEDCOM RSG2488
User Guide
Chapter 4
System Administration
Configuring the RADIUS Server 107
Section 4.6.1.1
Configuring the RADIUS Server
The Vendor-Specific attribute (or VSA) sent to the RADIUS server as part of the RADIUS request is used to
determine the access level from the RADIUS server. This attribute may be configured within the RADIUS server
with the following information:
Attribute Value
Vendor-Specific Vendor-ID: 15004
Format: String
Number: 2
Attribute: { Guest, Operator, Admin }
NOTE
If no access level is received in the response packet from the RADIUS server, access is denied.
Section 4.6.1.2
Configuring the RADIUS Client
The RADIUS client can be configured to use two RADIUS servers: a primary server and a backup server. If the
primary server is unavailable, the device will automatically attempt to connect with the backup server.
NOTE
The RADIUS client uses the Password Authentication Protocol (PAP) to verify access.
To configure access to either the primary or backup RADIUS servers, do the following:
1. Navigate to Administration > Configure Security Server > Configure RADIUS Server. The RADIUS Server
table appears.
Figure 69: RADIUS Server Table
2. Select either Primary or Backup from the table and press Enter. The RADIUS Server form appears.
Figure 70: RADIUS Server Form
1. Server Box 2. IP Address Box 3. Auth UDP Port Box 4. Auth Key Box 5. Confirm Auth Key Box 6. Apply Button
7. Reload Button

RuggedCom RSG2488 Specifications

General

Brand	RuggedCom
Model	RSG2488
Category	Switch
Language	English
