3. Installing the Product Confidential
82 English 8/2019. Rev 0.0
35. Connect Battery Module #16 B+ and Battery Module #17 B- using “BUS-BAR MAIN”. Connect using M8 screw.
Figure 3-85: Connect Battery Module #16 B+ and Battery Module #17 B-.
