Confidential 2. Product Description
English 8/2019. Rev 0.0 11
SMPS Assembly with 3 Phase AC Input
SMPS Assembly with 1 Phase AC Input
Type B (without System BMS)
Figure 2-8: SMPS Assembly Type B
Figure 2-9: Front View of SMPS Assembly Type A, 3-Phase Input
Figure 2-10: Front View of SMPS Assembly Type A, 1-Phase Input
Figure 2-11: SMPS Assembly Type A – System BMS Connections
