10. Connect the signal cable “WIRE ASSY MODULE TO MODULE #1" from Module #9 “Left Connector” to
Module #10 “Right Connector.”
Figure 3-99: Module #9 to Module #10 Signal Cabling
11. Connect the signal cable “WIRE ASSY MODULE TO MODULE #1" from Module #10 “Left Connector” to
Module #11 “Right Connector.”
Figure 3-100: Module #10 to Module #11 Signal Cabling
To Next Page
