Confidential 3. Installing the Product
English 8/2019. Rev 0.0 93
16. Connect the signal cable “WIRE ASSY MODULE TO MODULE #1" from Module #15 “Left Connector” to
Module #16 “Right Connector.”
Figure 3-105: Module #15 to Module #16 Signal Cabling
17. Connect the signal cable “WIRE ASSY MODULE TO MODULE #1" from Module #16 “Left Connector” to
Module #17 “Right Connector”.
No connection to Module #17 “Left Connector” is needed.
Figure 3-106: Module #16 to Module #17 Signal Cabling
