Samsung 136S - Table 2-5: Dry Contact Connector Description; Table 2-6: AC Terminal Description (3 Phase); Table 2-7: AC Terminal Description (1 Phase)

2. Product Description Confidential
14 English 8/2019. Rev 0.0
Table 2-5: Dry Contact Connector Description
Item
Part Name
Description
Connector
S12B-J11DK-TXR
JST
Harness Housing
J11DF-12V-KX
-
Harness Terminal
SF1F-21T-P0.6
AWG 18~22
Pin No.
Pin Name
Function
1A
DRY CONTACT 0 NC
Refer to the product specification.
2A
DRY CONTACT 1 COM
3A
DRY CONTACT 1 NO
4A
DRY CONTACT 2 NC
5A
-
6A
DRY CONTACT IN- (GND)
1B
DRY CONTACT 0 COM
2B
DRY CONTACT 0 NO
3B
DRY CONTACT 1 NC
4B
DRY CONTACT 2 COM
5B
DRY CONTACT 2 NO
6B
DRY CONTACT IN+
Table 2-6: AC Terminal Description (3 phase)
Item
Part Name
Description
Terminal Block
SL3T-4P
Seoil Electronics
Terminals
Ring terminal
320 ~ 575VAC, 6A
Pin No.
Pin Name
Function
1
L1
3 phase AC, L1
2
L2
3 phase AC, L2
3
L3
3 phase AC, L3
4
PE
-
Table 2-7: AC Terminal Description (1 phase)
Item
Part Name
Description
Terminal Block
SL3T-4P
Seoil Electronics
Terminals
Ring terminal
100 ~ 240VAC, 6A
Pin No.
Pin Name
Function
1
L1
SMPS #1 1 phase AC, L
2
N1
SMPS #1 1 phase AC, N
3
L2
SMPS #2 1 phase AC, L
4
N2
SMPS #2 1 phase AC, N
