3. Installing the Product Confidential
34 English 8/2019. Rev 0.0
Figure 3-10: Rear panel hooks (four)
3. Arrange the rack frame after verifying that the holes in the frame and anchoring points are aligned.
4. Connect four anchoring points on the bottom of the rack.
NOTICE
 Anchor the frame with M16 bolts and nuts.
 The fastening torque should be 140Nm / 1,425kgf cm.
 Check the rack and other parts for distortion caused by unpacking.
Figure 3-11: Rack Anchoring Points (4 EA)
Bottom of the Rack Frame
