Samsung 136S - Figure 3-2: Clearance Distance for Single Rack Frame; Figure 3-3: Clearance Distance for Multiple Rack Frames Installed Side-By-Side

3. Installing the Product Confidential
30 English 8/2019. Rev 0.0
Configuration
Anchor points per rack
Clearance Distance (mm)
Side (end)
Side (adjacent)
Rear
Front
(Side-to-Side
and Rear-to-
Rear)
not rated for seismic event
(1000 recommended)
4 (All) – Telcordia Zone 4
Workable distance
(800 recommended)
0
Workable distance
(800 recommended)
Workable distance
(1000 recommended)
Two anchor points (not rated for seismic event)
Four anchor points (Telcordia Zone 4)
Figure 3-2: Clearance Distance for Single Rack Frame
Two anchor points (not rated for seismic event)
Four anchor points (Telcordia Zone 4)
Figure 3-3: Clearance Distance for Multiple Rack Frames Installed Side-by-Side
