3. Installing the Product Confidential
20 English 8/2019. Rev 0.0
3.3 Installation Procedure
This product must be installed by following the procedure below:
Figure 3-1: Installation Procedure
 Preparation Stage
 Procedure
 Unpacking
 Ground Wire and Tools
 Recommended Tools/Instruments
 Appearance Inspection
 Rack Anchoring Stage
 Transport the rack frame to the installation location after unpacking
 Arrange the rack frame after checking the positions of holes in the frame and anchoring points
 Perform the anchoring and ground connections
 Rack Installation Stage
 Transport the battery modules to the installation location
 Insert the SMU in the rack frame
 Insert the SMPS Assembly in the rack frame
 After all components are inserted in the rack frame, attach them to the rack frame
 Place the battery modules in the rack frame
 Connect the busbars
 Connect the signal cables from SMU to module, and module to module
 Connect the signal cables from SMU to SMU
 System Installation Stage
 Connect the SMPS Assembly to AC power source
 Prepare the items for BMS configuration
 Configure the BMS
 Perform installation checks
Estimated time for each step is listed below.
1. Preparation
Stage
2. Rack Anchoring
Stage
3. Rack
Installation
Stage
4. System
Installation Stage
