Confidential 3. Installing the Product
English 8/2019. Rev 0.0 55
Figure 3-42: Remove Battery Module #2’s Front Cover
7. Connect Battery Module #2 B+ and Battery Module #3 B- using “BUS-BAR MAIN.” Connect using an M8 screw.
Figure 3-43: Connect Battery Module #2 B+ and Battery Module #3 B-.
