Table 11: SMPS Status (SMPS Assembly 1 Phase Only)
Item
Part Name
Description
Connector
J21SPM-04V-KX
-
Harness Housing
J21SF-04V-KX-L
-
Harness Terminal
SJ2F-01GF-P1.0
AWG 20~24
Pin No.
Pin Name
Function
1
SMPS #1 STATUS (+)
SMPS #1 status
2
SMPS #1 STATUS (-)
SMPS #1 status
3
SMPS #2 STATUS (+)
SMPS #2 status
4
SMPS #2 STATUS (-)
SMPS #2 status
