SatLab SLT2 - Fixed Point Management

Total Station Manual
-
155
-
Steps
Key
Display
○
1 In the menu of Job Manager,
press [F2] to enter the interface of
Fix Pt. function.
[F2]
○
2
The interface displays the
fixpoints of the current job.
Pressing the direction key of left
or right can scan all fixpoints in
the job. Press [F4] to switch to
the second page’ soft key.
[F4]
+
[F2]
○
3 Press [F2](Job) to enter the list
of job, press the direction key of
up or down to select the job
which the viewed fixpoints exist,
then press [F4] to make sure. ※
1
[F4]
○
4
Program displays the data of
fixpoints in the corresponding job.
Press the direction key of left or
right can view all fixpoints in the
job.
[←]
[→]
※
1
: The selected job is only used to view fixpoints and it will not be set as current
job.
2.1 Search Fix Pt.
Input the name of point or “*” to view the fixpoints in the selected job.
