SatLab SLT2 - Add Fix Pt

Total Station Manual
-
156
-
Steps
Key
Display
○
1
In the interface of View
FixPoints, pressing [F1] (Find) to
enter the function of finding
fixpoints.
[F1]
○
2 There appears a dialog as shown
in the picture on the right. Input
the name of point or the wildcard
of “*”, press [ENT] to make sure
and press [F4] (OK) to find.
[ENT]
+
[F4]
○
3 Displaying the dialog of finding
result.
If the point exists in the job, the
interface will display the coordinate
information of the point.
If input the wildcard of “*”, you can
view all fixpoints by pressing the
direction key of left or right.
2.2 Add Fix Pt.
Steps
Key
Display
○
1 In the interface of View
FixPoint, pressing [F2] (New) to
enter the function of new fixpoint.
If you want to change the job
which need to new points, you can
press [Job] to select the target job.
[F2]
