11.9 Extension
Use the Extension sub application to calculate the coordinate of extended point
from a known baseline.
Figure 11.9 Extension Diagram
Known
P1 Baseline Start Point
P2 Baseline End Point
L1, L2 Extension Distance
Unknown
P2, P4 Extended COGO Point
Steps
Key
Display
○
1 In the [COGO Menu]
screen, press the [F4] or
number key [4] enter the
[Extension] screen.
[F4]
or
[4]
