MRD 3187B - User Manual
Page 120 (245)
1.
Use the
and
buttons to mov
e
the cursor to “Pa
ckets/Frame:
” then
press the
button.
2.
Use the
and
buttons to
specify the number
of IP pa
ckets to be
transmitted pe
r MPEG fr
ame (1-7),
then press the
button to sav
e the
selection.
MPEG/IP 1
-3
Diff
Serv:Defaul
t
Src
Port:00000
►Pack
ets/Frame:7
120
