MRD 3187B - User Manual
Page 156 (245)
Audio 2 PID
1. Use the and buttons to
move the cursor to “Aud 2 PID:”
then press the button.
2. Use the and buttons to
select the column to edit and use
the and buttons to set the
PID, then press the button to
save the selection.
Audio 3 PID
1. Use the and buttons to
move the cursor to “Aud 3 PID:”
then press the button.
2. Use the and buttons to
select the column to edit and use
the and buttons to set the
PID, then press the button to
save the selection.
Audio 4 PID
1. Use the and buttons to
move the cursor to “Aud 4 PID:”
then press the button.
2. Use the and buttons to
select the column to edit and use
the and buttons to set the
PID, then press the button to
save the selection.
Priority Mode
This mode is generally used with two identical streams for redundancy.
Priority 1
1. Use the and buttons to
move the cursor to “Priority 1:”
then press the button.
2. Use the and buttons to
select either “Manual” or “List”,
then press the button to save
the selection.
Note: In “List” mode, the MRD 3187B will only allow the Services to be
selected that are in the PMT. The “Manual” mode is shown.
Note: “List” mode is only selectable when the input is receiving a PMT.
Serv Setup
Tune Mode:Priority
►Priority 1:Manual
Service:
Serv Setup ←→
Aud 2 PID:0x0035
Aud 3 PID:0x0036
►Aud 4 PID:0x0000
Serv Setup ←→
Aud 1 PID:0x0034
Aud 2 PID:0x0035
►Aud 3 PID:0x0000
Serv Setup ←→
Video PID :0x0031
Aud 1 PID:0x0034
►Aud 2 PID:0x0000
