Reference,” under the button, must be set to the type of Genlock signal being
used as well. If the Genlock input source is lost, the red “Error” LED will illuminate on
the front panel, a description of the error will be shown in the “Active Errors” menu
under the button, and an entry will be logged in the event log. The video will
restore but will not be Genlocked until the Genlock signal is restored.
When the “Genlock Reference” is set to an SD source of NTSC or PAL, the “Genlock
Offset” includes a “Color Ref” setting.
Note: This mode is only available if the unit is equipped with an 8731A/8734 decoder
as well as the 8704A/8704B video output card.
6. Use the and buttons to move the
cursor to “Genlock Offset,” then press the
button.
Vertical
7. Use the and buttons to move
the cursor to “Vert:” then press the
button.
8. Use the and buttons to select
the column to edit and use the and
buttons to change the number of
lines, then press the button to
save the selection.
Note: The maximum amount of offset is determined by the format of the video
set.
Horizontal
1. Use the and buttons to move
the cursor to “Horiz:” then press the
button.
2. Use the and buttons to select
the column to edit and use the and
buttons to change the number of
pixels, then press the button to
save the selection.
Note: The maximum amount of offset is determined by the format of the video
set.
Color Reference
Note: The Color Reference is only available when the Genlock reference is SD.
Genlock Offset
Vert:-125 lines
►Horiz:-0177 pixels
Color Ref:-100
Genlock Offset
►Vert:-125 lines
Horiz:-0177 pixels
Color Ref:-100
SD Video 1-1
Video
►Genlock Offset
SDI VANC Assignment
