MRD 3187B - User Manual
Page 38 (245)
1. Use the and buttons to move
the cursor to “Line 21CC:” then press
the button.
2. Use the and buttons to select
“Enabled” or “Disabled”, then press the
button to save the selection.
Note: Repeat steps 1-2 above to change AMOL and TVG2x.
PAL Waveforms
To enable PAL items, use the following steps.
1. Use the and buttons to move
the cursor to “TTX:” then press the
button.
2. Use the and buttons to select
“Enabled” or “Disabled”, then press the
button to save the selection.
Note: Repeat steps 1-2 above to change VPS and WSS.
Composite VBI Assignment
To edit the Composite VBI Assignment, use the following steps.
1. Use the and buttons to move the
cursor to “Cmpst VBI Assignment” then
press the button to display the status
screen for the VBI.
2. Press the button once more to enter
the Edit screen.
NTSC Waveforms
To enable NTSC items, use the following steps.
1. Use the and buttons to move
the cursor to “Line21 CC:” then press
the button.
2. Use the and buttons to select
“Enabled” or “Disabled”, then press the
button to save the selection.
Note: Repeat steps 1-2 above to change AMOL, and TVG2x.
PAL Waveforms
To enable PAL items, use the following steps.
1. Use the and buttons to move
the cursor to “TTX:” then press the
button.
2. Use the and buttons to select
“Enabled” or “Disabled”, then press the
button to save the selection.
Note: Repeat steps 1-2 above to change VPS, and WSS.
Cmpst VBI 1-1
PAL
► TTX:Enabled
VPS:Disabled
Cmpst VBI 1-1
NTSC
► Line21 CC:Enabled
AMOL:Disabled
SD Video 1-1
Genlock Offset
SDI VANC Assignment
►Cmpst VBI Assignment
SDI VANC 1-1
PAL Waveforms
► TTX:Enabled
VPS:Disabled
SDI VANC 1-1
NTSC Waveforms
► Line 21CC:Enabled
AMOL:Disabled
