MRD 3187B - User Manual
Page 44 (245)
Video Format
Note: This menu is only available if the “Select Format” option is set to “Manual.”
1. Use the and button to move
the cursor to “Format:” then press the
button.
2. Use the and buttons to
select the desired output format, then
press the button to save the
selection.
720x480i
16x9
29.97
1920x1080i
16x9
29.97
720x480i
4x3
29.97
1920x1080i
16x9
30.00
720x576i
16x9
25.00
1920x1080PsF
16x9
23.98
720x576i
4x3
25.00
1920x1080PsF
16x9
24.00
1280x720p
16x9
50.00
1920×1080p
16×9
23.98
1280x720p
16x9
59.94
1920×1080p
16×9
24.00
1280x720p
16x9
60.00
1920×1080p
16×9
25.00
1920x1080i
16x9
25.00
1920×1080p
16×9
29.97
1920×1080p
16×9
30.00
Note: “If either 480i or 576i video format is used the HD-SDI outputs are
turned off and only the analog output is enabled.
Analog Output Format
Note: If this setting is set incorrectly when using an RGB monitor, the image will
appear green. If this setting is set incorrectly when using a Component monitor,
there will be no video on the monitor.
1. Use the and buttons to move
the cursor to “Anlg Out:” then press
the button.
2. Use the and buttons to
select the desired output format
(“RGBHV”, “YPbPr”), then press the
button to save the selection.
Display Mode
1. Use the and buttons to move
the cursor to “Disp Mode:” then press
the button.
2. Use the and buttons to
select the desired output size
(“Letterbox”, “Cropped”), then press
the button to save the selection.
Auto AFD
AFD or Active Format Description, is a standard set of codes that if sent in the
MPEG transport stream is interpreted by the MRD 3187B into a certain aspect
ratio and active picture characteristics.
HD Video 2-1
16x9 29.97
Anlg Out:RGBHV
►Disp Mode:Letterbox
HD Video 2-1
Format:1920x1080i
16x9 29.97
►Anlg Out:RGBHV
HD Video 2-1
Select Format:Manual
►Format:1920x1080i
16x9 29.97
