Channel Bandwidth B
1. Use the and buttons to move
the cursor to “Channel BW:” then
press the button.
2. Use the and buttons to
change the channel bandwidth (“6
MHz”, “7 MHz”, “8 MHz”), then press
the button to save the selection.
Spectrum B
1. Use the and buttons to move
the cursor to “Spectrum:” then press
the button.
2. Use the and buttons to
change the spectrum (“Normal”,
“Inverted”), then press the button
to save the selection.
Dual COFDM 1-4
Center Freq:050MHz
Channel BW:8 MHz
► Spectrum:Normal
Dual COFDM 1-4
Input B
Center Freq:050MHz
► Channel BW:8 MHz
