The SL DI 4 XLR Dante™ interface

142

Daisy-chaining the power supply

The PWR LINK IN and OUT terminals allow you to daisy-chain the power

supply to additional devices.

The number of devices that can be daisy-chained is limited.

•NT 12-50CS power supply -> maximum of 3 devices

• Power over Ethernet -> maximum of 2 devices

WARNING!

Danger of injury due to missing overload protection!

If the daisy-chaining of the power supply is not done properly, this may

cause injury due to electric shock.

▷ Only have the daisy-chaining of the power supply done by a qualified

specialist.
