The Products of the SpeechLine Digital Wireless Series

The Dante™ interface

►

The SL DI 4 XLR is a Dante™ interface with four inputs. This lets you inte-

grate wireless microphone receivers or mic/line inputs into a Dante™ sys-

tem. The compact design of the SL DI 4 XLR allows it be mounted almost

anywhere, enabling close placement to audio sources and thus reducing

the need for interference-prone analog cables.
