Sennheiser CHG 2W - The CHG 2 W Charging Base

To Next Page

To Previous Page

The Products of the SpeechLine Digital Wireless Series

The CHG 2W charging base

►

The CHG 2W is a wireless charging base that provides convenient wireless

charging.

The CHG 2W charging base is compatible with the SL Tablestand 133-S

DW, the SL Tablestand 153-S DW and the SL Boundary 114-S DW.
