The Products of the SpeechLine Digital Wireless Series

The CHG 4N charger

►

The CHG 4N is a network-compatible charger with four separate charging

slots. These ports can be used for the SL Bodypack DW and the SL Hand-

held DW. The four LEDs on each charging slot indicate the current

charging status. The versatile network interface is compatible with IPv4

and IPv6 for seamless integration. The Sennheiser Control Cockpit soft-

ware can be used to monitor and remotely control the settings and status

messages.
