The CHG 2W charging base

166

Product overview

►

1 Charging surface for wireless energy transfer

• For the SL Tablestand 133-S DW and SL Tablestand 153-S DW units

2 Socket for power supply unit

• See „Connecting the CHG 2W charging base to the power supply

system”

3 Status LEDs

• Flashing: device is charging

• Flashing rapidly: temperature too high

• Flickering: unknown device on the charger

• See „Meaning of the status LEDs on the charging surfaces”
