Planning

At the start of planning, the following aspects are to be considered.

Country-Specific Variants

Check which country variant of SpeechLine Digital Wireless is suitable for

your location. The following eight country variants are available.

-3 EU Variant:

►

-3 UK Variant:

►

-3 AU Variant:

►

-4 EU Variant:

►
