The SL Handheld DW
87
Meaning of the status LED on the handheld transmitter
lights up green:
• A radio link to the receiver is established. The accupack of the handheld
transmitter is sufficiently charged.
flashes green:
•The PAIR button has been short-pressed. Paired devices are being iden-
tified.
flashes alternately green and red:
•The PAIR button has been long-pressed. The handheld transmitter es-
tablishes a radio link to a receiver whose PAIR button has also been
long-pressed.
lights up yellow:
• The handheld transmitter has been muted with theMUTE switch. In ad-
dition, Muted is displayed on the display panel.
flashes yellow:
• The firmware is being updated.
lights up red:
• No radio link to a receiver. In addition, No Link is displayed on the dis-
play panel.
flashes red:
• The accupack capacity of the handheld transmitter is only sufficient for
max. 30 minutes of operation.
