The Products of the SpeechLine Digital Wireless Series

The wireless SL Boundary 114-S DW

►

The wireless SL Boundary 114-S DW boundary microphone is designed for

your speech.

Because it is completely cable free, the SL Boundary 114-S DW is extremely

versatile and suited for a wide range of applications.

The SL Boundary 114-S DW can be charged either wirelessly or via USB.

The CHG 2W wireless charging base for two mobile devices is available

separately. The SL Boundary 114-S DW is delivered with a rechargeable

battery that lasts up to 10 hours.

The Sennheiser Control Cockpit software can be used to monitor and con-

trol the wireless boundary microphone remotely.
