Using the operating menu of the receiver

Using the buttons for navigation

Press the STANDBY button

• Short-press: Switches the receiver on

• Long-press: Switches the receiver off

Short-press the ESC button

• Navigates to the next higher level in the menu

• Exits the menu item without storing changes to the settings

Press the ESC button for 3 seconds

• Returns to the home screen

Press the jog dial

Changes from the home screen to the operating menu

• Calls up the selected menu item

• Changes to the selected submenu

• Confirms the selection or the changed setting

Turn the jog dial

• Switches between the home screen and the secondary home screen

• Changes to the previous or next menu item

• Changes the settings of a menu item

SHORT

esc

LONG

esc
