The SL DI 4 XLR Dante™ interface

150

IN 3 input: ERR

►

The PAD and +15 LEDs of the IN 3 in-

put light up:

Capability is corrupted

►

The +15 LED of the IN 3 input lights

up:

Memory Stack Overflow

►

IN 4 input: SYS

►

The +15 LED of the IN 4 input lights

up:

System starts up

►

The PAD LED of the IN 4 input lights

up:

System is ready for operation
