The AWM 2 antenna wall mount
174
ing directly trough a wall. When wall mounting the antenna wall mount,
observe a minimum distance of 160 mm between the top of the antenna
wall mount and the ceiling.
▷ If necessary, connect extension cables to the R-SMA sockets of the an-
tenna wall mount.
▷ Connect the R-SMA connectors to the R-SMA sockets of the receiver.
You can find additional information on possible setups using the
AWM 2 and general recommendations on antenna usage under „Rec-
ommendations on antenna mounting”.
