5.4 Analysis Using Queues
5-13
CBM-20A/20Alite
5
 Putting the Analysis Queue in Waiting Status
An analysis queue can be put in waiting status between sequences in the queue by inserting
WaitSeq lines in the analysis-queue table.
1
Select the first sequence to be executed after the analysis queue is put in waiting
status by clicking the box on the left of the filename.
The selected line turns light blue.
Lines that are being or have already been executed cannot be selected.
2
Click .
A WaitSeq line is inserted above the selected line.
5.4.3 Starting Analysis
The method for starting analysis based on an analysis queue is the same as that for standard
analysis.
1
Click the [Analysis] tab.
The "Analysis" tab page is displayed.
2
Click .
Analysis starts.
5.4.4 Clearing Waiting Status
When an analysis queue comes to a WaitSeq line in an analysis-queue table, the status
display changes to [WaitSeq] and the queue enters waiting status. There are two methods for
clearing waiting status: one is used in the "Analysis" tab page and the other is used in the
"Queue" tab page.
 Clearing Waiting Status from the "Analysis" Tab Page
1
Click the [Analysis] tab.
The "Analysis" tab page is displayed.
2
Click the pause button.
Waiting status is cleared and the next analysis sequence is executed.
 Clearing Waiting Status from the "Queue" Tab Page
1
Click the [Queue] tab.
The analysis-queue table is displayed.
2
Click .
Waiting status is cleared and the next analysis sequence is executed.
