2. Parts Identification and Function
2-6
CBM-20A/20Alite
2.4 Applications and Windows
The components in an LC system can be controlled from Internet Explorer running on a PC by
accessing the system controller's Web server.
There are four basic applications (programs) that can be executed from the system
controller's Web server: the "Group Monitor" application, the "Analysis Execution" application,
the "System Check" application, and the "Group Settings" application.
Each application consists of a main window divided into sections with tab pages and sub-
windows that are opened from inside the application.
The windows for the "Group Monitor" and "Analysis Execution" applications as well as the
"Login" and "Error" windows that are displayed when operating the system controller are
described in the following section.
Refer to "8.1 Checking the System" P. 8-2 for the system check aplication.Refer to "5.9 Managing
Groups" P. 5-39 for the group management.
